The FW105 features one addressable loop circuit (SLC) with 252 addressable devices/points as well as 6 auxiliary function buttons and 12 LED indicators. Capabilities Network supports up to 32 panels (Class X) or 109 remote annunciators or panels (Class B) Compliance UL/ULC Listed Built-In Annunciator Built-in 30 LED/buttons annunciator 10A power dedicate for signaling circuits Comes with 4 NAC that can be expanded to 8 NAC; 2 Amp per circuit 2 RS232, 1 USB, and 1 RJ45 port on the panel 4 Optional SLC isolator circuits available (Expandable to 8 isolators Class B)
